TQTextBrowser Class Reference

The TQTextBrowser class provides a rich text browser with hypertext navigation. More...

#include <tqtextbrowser.h>

Inherits TQTextEdit.

List of all member functions.

Public Members

Public Slots

Signals

Properties

Protected Members


Detailed Description

The TQTextBrowser class provides a rich text browser with hypertext navigation.

This class extends TQTextEdit (in read-only mode), adding some navigation functionality so that users can follow links in hypertext documents. The contents of TQTextEdit is set with setText(), but TQTextBrowser has an additional function, setSource(), which makes it possible to set the text to a named document. The name is looked up in the text view's mime source factory. If a document name ends with an anchor (for example, "#anchor"), the text browser automatically scrolls to that position (using scrollToAnchor()). When the user clicks on a hyperlink, the browser will call setSource() itself, with the link's href value as argument. You can track the current source by connetion to the sourceChanged() signal.

TQTextBrowser provides backward() and forward() slots which you can use to implement Back and Forward buttons. The home() slot sets the text to the very first document displayed. The linkClicked() signal is emitted when the user clicks a link.

By using TQTextEdit::setMimeSourceFactory() you can provide your own subclass of TQMimeSourceFactory. This makes it possible to access data from anywhere, for example from a network or from a database. See TQMimeSourceFactory::data() for details.

If you intend using the mime factory to read the data directly from the file system, you may have to specify the encoding for the file extension you are using. For example:

    mimeSourceFactory()->setExtensionType("qml", "text/utf8");

This is to ensure that the factory is able to resolve the document names.

TQTextBrowser interprets the tags it processes in accordance with the default style sheet. Change the style sheet with setStyleSheet(); see TQStyleSheet for details.

If you want to provide your users with editable rich text use TQTextEdit. If you want a text browser without hypertext navigation use TQTextEdit, and use TQTextEdit::setReadOnly() to disable editing. If you just need to display a small piece of rich text use TQSimpleRichText or TQLabel.

See also Advanced Widgets, Help System, and Text Related Classes.


Member Function Documentation

TQTextBrowser::TQTextBrowser ( TQWidget * parent = 0, const char * name = 0 )

Constructs an empty TQTextBrowser called name, with parent parent.

void TQTextBrowser::anchorClicked ( const TQString & name, const TQString & link ) [signal]

This signal is emitted when the user clicks an anchor. The link is the value of the href i.e. the name of the target document. The name is the name of the anchor.

See also linkClicked().

void TQTextBrowser::backward () [virtual slot]

Changes the document displayed to the previous document in the list of documents built by navigating links. Does nothing if there is no previous document.

See also forward() and backwardAvailable().

Example: helpviewer/helpwindow.cpp.

void TQTextBrowser::backwardAvailable ( bool available ) [signal]

This signal is emitted when the availability of backward() changes. available is FALSE when the user is at home(); otherwise it is TRUE.

Example: helpviewer/helpwindow.cpp.

void TQTextBrowser::forward () [virtual slot]

Changes the document displayed to the next document in the list of documents built by navigating links. Does nothing if there is no next document.

See also backward() and forwardAvailable().

Example: helpviewer/helpwindow.cpp.

void TQTextBrowser::forwardAvailable ( bool available ) [signal]

This signal is emitted when the availability of forward() changes. available is TRUE after the user navigates backward() and FALSE when the user navigates or goes forward().

Example: helpviewer/helpwindow.cpp.

void TQTextBrowser::highlighted ( const TQString & link ) [signal]

This signal is emitted when the user has selected but not activated a link in the document. link is the value of the href i.e. the name of the target document.

Example: helpviewer/helpwindow.cpp.

void TQTextBrowser::home () [virtual slot]

Changes the document displayed to be the first document the browser displayed.

Example: helpviewer/helpwindow.cpp.

void TQTextBrowser::keyPressEvent ( TQKeyEvent * e ) [virtual protected]

The event e is used to provide the following keyboard shortcuts:
Keypress Action
Alt+Left Arrow backward()
Alt+Right Arrow forward()
Alt+Up Arrow home()

Reimplemented from TQTextEdit.

void TQTextBrowser::linkClicked ( const TQString & link ) [signal]

This signal is emitted when the user clicks a link. The link is the value of the href i.e. the name of the target document.

The link will be the absolute location of the document, based on the value of the anchor's href tag and the current context of the document.

See also anchorClicked() and context().

void TQTextBrowser::reload () [virtual slot]

Reloads the current set source.

void TQTextBrowser::setSource ( const TQString & name ) [virtual slot]

Sets the name of the displayed document to name. See the "source" property for details.

TQString TQTextBrowser::source () const

Returns the name of the displayed document. See the "source" property for details.

void TQTextBrowser::sourceChanged ( const TQString & src ) [signal]

This signal is emitted when the mime source has changed, src being the new source.

Source changes happen both programmatically when calling setSource(), forward(), backword() or home() or when the user clicks on links or presses the equivalent key sequences.

Example: helpviewer/helpwindow.cpp.


Property Documentation

bool modified

This property holds whether the contents have been modified.

bool overwriteMode

This property holds this text browser's overwrite mode.

bool readOnly

This property holds whether the contents are read only.

TQString source

This property holds the name of the displayed document.

This is a TQString::null if no document is displayed or if the source is unknown.

Setting this property uses the mimeSourceFactory() to lookup the named document. It also checks for optional anchors and scrolls the document accordingly.

If the first tag in the document is <qt type=detail>, the document is displayed as a popup rather than as new document in the browser window itself. Otherwise, the document is displayed normally in the text browser with the text set to the contents of the named document with setText().

If you are using the filesystem access capabilities of the mime source factory, you must ensure that the factory knows about the encoding of specified files; otherwise no data will be available. The default factory handles a couple of common file extensions such as *.html and *.txt with reasonable defaults. See TQMimeSourceFactory::data() for details.

Set this property's value with setSource() and get this property's value with source().

int undoDepth

This property holds this text browser's undo depth.

bool undoRedoEnabled

This property holds whether undo and redo are enabled.
